Description

Key Features

SMBB Technology:
Better light trapping and current collection to improve module power output and reliability.
Hot 2.0 Technology:
The N-type module with Hot 2.0 technology has better reliability and lower LID/LETID.
PID Resistance:
Excellent Anti-PID performance guaranteed via optimized mass-production process and materials control.
Enhanced Mechanical Load:
Certified to withstand: wind load (4000 Pascal) and snow load (6000 Pascal).
Sustainability Against Extreme Environmental Conditions:
High salt mist and ammonia resistance.

Linear Performance Warranty

25 Year Product Warranty
30 Year Linear Power Warranty
0.40% Annual Degradation Over 30 years

Mechanical Characteristics

Cell Type: N type Mono-crystalline
No. of cells: 108 (6×18)
Dimensions: 1762×1134×30mm (69.36×44.65×1.18 inch)
Weight: 22 kg (48.50 lbs)
Front Glass: 3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass
Frame: Anodized Aluminum Alloy
Junction Box: IP68 Rated
Output Cables: TUV 1×4.0mm2 (+): 400mm , (-): 200mm or Customized Length

Specifications

• Marque: Jinko

Pros and cons

• Énergie propre et renouvelable
• Grande fiabilité et longue durée de vie
• Faibles besoins en maintenance
• La production varie selon les conditions météorologiques
• Nécessite une installation correcte pour éviter les problèmes
