Rigid Panels

Mechanical Characteristics N-TOPCon monocrystalline cells, 16 busbars Cables approx. 110 cm Black anodized aluminum frame, white backsheet Glass thickness 1.6/1.6mm Stäubli MC4 EVO2 connectors Trina Solar TS 303X junction box Item Details Intrastat country of origin    China Manufacturer article designation    TSM-500NEG18R.28 Certificate 1    IEC/TÜV Intrastat product number (HS-Code)    85414300 Certificate 2    Protection Class 2 Manufacturer    Trina Solar Dimensions Length without packaging (mm)    1961.00 Weight without packaging (kg)    23.500 Width without packaging (mm)    1134.00 Height without packaging (mm)    30.00 Packaging Length including packaging (cm)    196.10 Width including packaging (cm)    113.40 Number per container    864 Size including packaging (cm)    3.00 Number of pallets per container    24 Weight including packaging (kg)    23.500 Quantity per pallet    36 Warranty Performance warranty (years)    30 Initial % for linear warranty    99 Linear degradation in %    0.4 Manufacturer warranty    Trina Solar Product warranty (years)    25 Technical Data Bifacial no Front glass thickness (mm) 1.60 Frame color black Maximum reverse current (A) 30 Max. system voltage (V) 1500 Backsheet color white Maximum wind speed capacity (Pa) 2400 Number of cells vertically 6 Nominal current Impp (A) 15.03 Pmpp temperature coefficient (%/C) -0.2900 Short-circuit current (A) 15.86 Module type dual-glass Uoc temperature coefficient (%/C) -0.2400 Number of cells horizontally 18 Maximum surface load capacity (Pa) 5400 Power tolerance +5 Wp Frame type framed Cell width (mm) 182.000 Cell type monocrystalline Integrated module optimization no Module efficiency (%) 22.50 Protection class IP68 Connector type MC4 Evo 2 Isc temperature coefficient (%/C) 0.0400 Nominal voltage Umpp (V) 33.30 Cable length (cm) maximum 140.00 Cable length minus (cm) 140.00 Cell length (mm) 105.000 Busbars (pieces) 16 Open-circuit voltage Uoc (V) 40.10 Number of cells (pcs) 108 Cell size half-cut cell Nominal power (Wp) 500   Click on the icons to download the following files: Datasheet (EN) User Guide Warranty Compatibility Statement Datasheet (FR)

Read more less

The Jinko Solar Tiger Neo 435Wp solar panel uses the latest generation N-Type TOPCon technology to offer excellent energy efficiency. Ideal for self-consumption photovoltaic installations, it combines performance, reliability, and a long lifespan. Main features SMBB Technology:Better light capture and current collection to improve power output and module reliability. Hot 2.0 Technology:The N-type module with Hot 2.0 technology offers improved reliability and reduced LID/LETID. PID Resistance:Excellent anti-PID performance guaranteed through optimized production processes and material control. Enhanced Mechanical Load:Certified to withstand wind load (4000 Pascal) and snow load (6000 Pascal). Durability in Extreme Environmental Conditions:High resistance to salt mist and ammonia. Linear Performance Warranty 25-year product warranty 30-year linear performance warranty Annual degradation of 0.40% over 30 years Mechanical Characteristics Cell type: N-type monocrystalline Number of cells: 108 (6×18) Dimensions: 1762×1134×30 mm (69.36×44.65×1.18 inches) Weight: 22 kg (48.50 lbs) Front glass: 3.2 mm, anti-reflective coating, high transmission, low-iron tempered glass Frame: Anodized aluminum alloy Junction box: IP68 rated Output cables: TUV 1×4.0 mm² (+): 1200 mm. Click on the icons to download the following files: Technical Datasheet User Guide Warranty

Read more less

Key Features SMBB Technology: Better light trapping and current collection to improve module power output and reliability. Hot 2.0 Technology: The N-type module with Hot 2.0 technology has better reliability and lower LID/LETID. PID Resistance: Excellent Anti-PID performance guaranteed via optimized mass-production process and materials control. Enhanced Mechanical Load: Certified to withstand: wind load (4000 Pascal) and snow load (6000 Pascal). Sustainability Against Extreme Environmental Conditions: High salt mist and ammonia resistance. Linear Performance Warranty 25 Year Product Warranty 30 Year Linear Power Warranty 0.40% Annual Degradation Over 30 years Mechanical Characteristics Cell Type: N type Mono-crystalline No. of cells: 108 (6×18) Dimensions: 1762×1134×30mm (69.36×44.65×1.18 inch) Weight: 22 kg (48.50 lbs) Front Glass: 3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass Frame: Anodized Aluminum Alloy Junction Box: IP68 Rated Output Cables: TUV 1×4.0mm2 (+): 400mm , (-): 200mm or Customized Length

Read more less
