Description

Main features

SMBB Technology :
Better light capture and current collection to improve output power and module reliability.

Hot 2.0 Technology :
N-type module with Hot 2.0 technology provides better reliability and reduced LID/LETID.

PID resistance :
Excellent anti-PID performance guaranteed through optimized production process and material control.

Improved mechanical load :
Certified to withstand wind load (4000 Pascal) and snow load (6000 Pascal).

Durability in the face of extreme environmental conditions :
High resistance to salt mist and ammonia.

Linear performance guarantee

• 25 year product warranty
• 30-year linear performance warranty
• Annual degradation of 0.40% over 30 years

Mechanical characteristics

• Cell type : N-type monocrystalline
• Number of cells : 108 (6×18)
• Dimensions : 1762×1134×30 mm (69.36×44.65×1.18 inches)
• Weight : 22 kg (48.50 lbs)
• Front glass : 3.2mm, anti-reflective coating, high transmittance, low iron tempered glass
• Frame : Anodized aluminum alloy
• Junction box : IP68 rating
• Output cables : TUV 1×4.0 mm² (+): 1200 mm.

Click on the icons to download the following files:

Technical sheet

User Guide

Guarantee

Specifications

• Marque: Jinko

Pros and cons

• Énergie propre et renouvelable
• Grande fiabilité et longue durée de vie
• Faibles besoins en maintenance
• La production varie selon les conditions météorologiques
• Nécessite une installation correcte pour éviter les problèmes
