Description

Dual MPPT: Equipped with two MPP trackers per module, it maximizes energy yield by optimizing the current conversion of each PV module.
Robust protection: The IP67 protection rating guarantees dust and water resistance, increasing the longevity and reliability of the inverter in various environments.
WiFi integration: Integrated WiFi facilitates real-time monitoring and system management via an intuitive user interface.
Rapid shutdown function: Increases safety by complying with DIN VDE V 0126-95 standard and ensures AC discharge in < 100 ms for rapid shutdown.
Simple installation: Designed for rapidly connectable balcony PV systems, it simplifies the installation process and reduces setup time.
Extended relay life: External relay designed to operate at low temperatures, offering a long lifespan and simpler maintenance.

Technical specifications
Max. PV input power (W): 210-560 (2 pieces)
Max. PV input voltage: 60 V.
Start-up voltage: 20 V
MPPT voltage range: 25-55 V.
Nominal PV input voltage: 42.5 V.
Max. Input short-circuit current (A) 19.5+19.5
Max. Operating PV input current (A) 13+13
Number of MPP trackers/number of strings per MPP tracker 2/1
AC output side:
Nominal AC output power: 800 W.
Max. AC output power: 800 VA
Nominal AC output current: 3.7/3.5 A.
Max. AC output current: 3.7/3.5 A.
Nominal output voltage/range: 220/230 V 0.85-1.1
CONNECTION TYPE: L/N/PE
Nominal output grid frequency/range (Hz): 50/45-55, 60/55-65
Max. Units per branch: 6
Power factor adjustment range: from 0.9 leading to 0.9 lagging
Total harmonic current distortion THDi: less than 3%
DC feeding current: less than 0.5% of In
Efficiency level:
Maximum efficiency level: 96.5%
Euro efficiency 96.0%
MPPT efficiency over 99%
Device protection:
DC reverse polarity protection
AC output overcurrent protection
AC output overvoltage protection
AC output short-circuit protection
Thermal protection
Monitoring of DC connector isolation impedance
Grid monitoring
Island protection monitoring
Ground fault detection
Surge protection
Communication interface: WiFi
Allowable altitude (m): 2000 m
Noise: ≤ 25 (dB)
Protection rating (IP): IP 67
Operating temperature range (°C): -40 to +60℃, > power reduction from 45℃

This text was translated by a machine.

Features

2 MPP trackers, module level monitoring
IP67 protection rating
WIFI communication
Rapid shutdown function
Simple installation, suitable for quick-mount balcony PV systems
Rapid 100 ms AC discharge, compliant with new
DIN VDE 0620-1 standard (200 ms) for
Human safety protection
Comprehensive NS protection with self-monitoring
External relay advantage with low temperature, long lifespan, simplified maintenance
With integrated WIFI

Scope of delivery

• Converter
• User manual.

Keywords

Deye, SUN-M80G4-EU-Q0, inverter, sine wave converter, voltage converter
