Description
The GE-F60 is an ideal high-voltage storage battery solution for home or commercial backup power needs, off-grid sites, frequency regulation, or renewable energy integration. It is compatible with photovoltaic solar, wind, diesel generator, and grid power systems.
✅ Key Features:
-
High storage capacity up to 230 kWh in a small footprint
-
Rated output power: 100 kW with 88% cycle efficiency
-
Smart temperature control: batteries remain below 38 °C during operation
-
Enhanced safety: automatic aerosol shutdown, multiple alarms, and ventilation
-
Reliable LFP technology: over 6000 cycles and 10-year warranty
-
Modular and scalable design: addition of MPPTs, charging modules, or generators
Technical Specifications
-
Cell Chemistry: LiFePO4 for stability and durability.
-
Module Energy: 5.12 kWh per module.
-
System Energy: 61.44 kWh total, with 55.29 kWh usable energy.
-
Charge/Discharge Current: Flexible options with 50 A recommended, 100 A nominal, and a 125 A peak discharge for 2 minutes at 25°C.
-
Operating Conditions: Charging temperature range of 0 to 55°C and discharge of -20 to 55°C.
-
Humidity and Altitude Tolerance: Designed to operate between 5% and 85% RH and at altitudes up to 2000m.
-
Enclosure Rating: IP55, ensuring protection against dust and low-pressure water jets.
-
Dimensions and Weight: 780 x 1056 x 2235 mm and approximately 1.2 T.
-
Installation: Floor-mounted for ease and convenience.
-
Cycle Life: More than 6000 cycles at 25°C ± 2°C with a 0.5 C charge/discharge rate, maintaining at least 70% of original capacity.
-
Warranty: 10-year product warranty, guaranteeing long-term reliability and customer satisfaction.
-
Certifications: CE, IEC62619, IEC62040, UN38.3, meeting international safety and quality standards.
Ideal Applications
The Deye GE-F60 series is versatile and can be used in a variety of settings, including:
- Residential energy storage
- Commercial and industrial energy management
- Emergency backup power
- Off-grid power solutions
- Renewable energy integration
