Description

SKU: RW-M6.1-B

The Deye RW-M 6.1-B LFP wall-mounted battery is the perfect solution for those looking for a reliable, flexible and environmentally friendly energy storage system with advanced features for optimum performance and safety.

Technical specifications:

• Battery Chemistry: LiFePO4
• Capacity: 120 Ah
• Energy: 6.14 kWh
• Rated DC power: Peak (2 minutes, 25℃) 150 kW
• Dimensions (L/H/D): 510 millimeters 740 millimeters 145 mm (without base)
• Weight: Approx. 58kg
• Operating temperature: Charge: 0~55℃ / Discharge: -20℃~55℃
• Storage temperature: 0℃~35℃
• Humidity: 5%～95%
• Altitude: ≤ 2000 m
• Warranty period: 10 years
• Energy flow: 20 MWh at 70% end of life
• Certifications: UN38.3, IEC62619, CE, IEC 0-21, VDE2510-50

The Deye RW-M 6.1-B is an advanced lithium iron phosphate (LFP) battery designed to provide reliable, safe and high-efficiency energy storage solutions for residential and commercial applications. With its advanced battery management system (BMS) and modular design, this battery ensures long cycle life, high power density and complete protection for your energy storage needs.

Main features:

1. Safety and longevity:
   • Cobalt-free LFP chemistry ensures safer operation.
   • Intelligent BMS provides comprehensive protection and extends service life.
   • Supporting high discharge power ensures reliability.
2. High efficiency:
   • High power density for efficient energy storage.
   • Operating voltage range from 43.2 V to 57.6 V.
   • Usable energy capacity of 5.53 kWh with a nominal voltage of 51.2V.
3. Flexible and scalable:
   • The modular design allows for easy expansion, supporting up to 32 units in parallel.
   • Maximum capacity of 196 kWh.
   • Suitable for various applications with limited installation space and limited load.
4. Practical and smart:
   • Self-networking battery modules for effortless maintenance.
   • Remote monitoring and firmware upgrades via USB stick.
   • CAN 2.0 and RS485 communication ports for seamless integration.
5. Respectful of nature:
   • Made from non-toxic and pollution-free materials.
   • Designed to be environmentally friendly.
6. Multi-purpose installation:
   • Supports wall and floor mounting configurations.
   • Saves installation space with flat design.
7. Robust construction:
   • IP65 rating for a rugged enclosure.
   • Works efficiently in a wide temperature range (-20℃ to 55℃).
   • Lifespan of ≥ 6000 cycles at 25℃.

Accessories included:

• Battery Hanging Board (RW-M6.1-B-Hboard): For wall mounting.
• Hybrid inverter cable (RW-M6.1-B-PCable1500): Length 1500 mm, waterproof terminals.
• Battery Parallel Cable (RW-M6.1-B-BCable300): Length 300mm, waterproof terminals.
• Fixed Brackets (RW-M6.1-B-Fixed Bracket): To secure the battery when mounted on the floor.

Click on the icons to download the following files:

Technical sheet

User Guide

Guarantee

Compatibility Statement

Safety data sheets

Specifications

• Marque: Deye

Pros and cons

• Énergie propre et renouvelable
• Grande fiabilité et longue durée de vie
• Faibles besoins en maintenance
• La production varie selon les conditions météorologiques
• Nécessite une installation correcte pour éviter les problèmes
